Technical Specifications | |
Imperial Metric | Dimension & weight |
Dimension & weight | |
Height | 240 mm |
Length | 212 mm |
Output size | 3/8" |
Weight | 2.932 lb |
Width | 74 mm |
Certifications, standards & directives | |
CCC certified | No |
CMIIT ID | 2022AJ0358 |
EAC certified | Yes |
EU Standard | EN 18031-1:2024||EN 300 328 V2.2.2||EN 300 |
440 V2.1.1||EN 301 893 V2.1.1||EN 301489-1 | |
V2.1.1||EN 301489-17 V3.1.1||EN | |
50566:2017||EN 55014-1:2017||EN 55014- | |
2:2015||EN 61000-6-1:2007||EN 61000-6- | |
2:2005||EN 61000-6-3:2007+A1||EN 61000-6- | |
4:2007+A1||EN 62841-1:2015||EN 62841-2-2:2015+AC1 | |
EU Legislation | (EU) 2022/30||2006/42/EC (MD)||2011/65/EU |
(RoHS)||2014/53/EU (RED)||2015/863/EU | |
(RoHS amendment) | |
ETL control number | 3008099 |
ETL listed | Yes |
ETL text | 6 - 62841-2-2 |
EU SAR value | 0.49 W/kg |
FCC ID | PVH 0965 |
IC ID | 5325A-0965 |
KC certified | No |
UK Regulations | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
UK Standard | EN 300 328 V2.2.2||EN 300 440 V2.1.1||EN 301 |
893 V2.1.1||EN 301489-1 V2.1.1||EN 301489-17 | |
V3.1.1||EN 50566:2017||EN 55014-1:2017||EN | |
55014-2:2015||EN 61000-6-1:2007||EN 61000- | |
6-2:2005||EN 61000-6-3:2007+A1||EN 61000-6- | |
4:2007+A1||EN 62841-1:2015||EN 62841-2-2:2015+AC1 | |
WEEE | 5 - Small equipment <50cm |
Torque | |
Torque range max | 14.7 ft-lb |
Torque range min | 3.7 ft-lb |
Design & Functions | |
Model type | Pistol |
Output type | Square, Male |
SCIP | 68c2f2d6-c770-45dc-b4e1-5cfc88785683 |
Shut-off system | Transducer |
Tool family | SRB |
Power | |
Motor power | 500 W |
Motor voltage type | d.c. |
Motor voltage | 38.1 V |
Battery information | |
Battery | Li-Io 18/36 V |
Type of battery | 1 Li-ion |
Weight incl. battery | 4.034 lb |
Noise & vibrations | |
Sound pressure | < 70 dB(A) |
Sound standard | ISO15744 |
Sound uncertainty pulse | 3 dB(A) |
Vibration standard | ISO28927-2 |
Vibration uncertainty pulse | 1,3 m/s² |
Vibration value | <2.5 m/s² |
Vibration value pulse | 9,5 m/s² |
Speed | |
Speed range max | 1500 r/min |
