Technical Specifications | |
Imperial Metric | Dimension & weight |
Dimension & weight | |
Height | 212 mm |
Length | 213 mm |
Output size | 1/4" |
Weight | 2.1 lb |
Certifications, standards & directives | |
CMIIT ID | 2016AJ1533 |
EAC certified | No |
EU Standard | EN 18031-1:2024||EN 301 489-1 V2.2.3||EN 301 |
489-17 V3.2.4||EN 301 489-33 V2.2.1||EN | |
61000-6-2:2019||EN 61000-6-4:2019||EN | |
62841-1:2015 + AC:2015 + A11:2022||EN 62841- | |
2-2:2014 + AC:2015 | |
EU Legislation | (EU) 2022/30||2006/42/EC (MD)||2011/65/EU |
(RoHS)||2014/53/EU (RED)||2015/863/EU | |
(RoHS amendment) | |
ETL control number | 3008099 |
ETL listed | Yes |
ETL text | 6 - 62841-2-2 |
EU SAR value | 0.54 W/kg |
FCC ID | PVH0965 |
IC ID | 5325A-0965 |
KC certified | Yes |
UK Regulations | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
UK Standard | EN 301 489-1 V2.2.3||EN 301 489-17 V3.2.4||EN |
301 489-33 V2.2.1||EN 61000-6-2:2019||EN | |
61000-6-4:2019||EN 62841-1:2015 + AC:2015 + | |
A11:2022||EN 62841-2-2:2014 + AC:2015 | |
WEEE | 5 - Small equipment <50cm |
Torque | |
Torque range max | 8.9 ft-lb |
Torque range min | 3 ft-lb |
Torque scatter 3s | ≤ 7.5 % |
Design & Functions | |
Communication type | Bluetooth/W-LAN |
Model type | Pistol |
MSIP | R-R-50A-XTB-P |
Output feature | Bit holder |
Output type | Hexagon, Female |
Shut-off system | Transducer |
Tool family | SB |
Power | |
Motor power | 290 W |
Motor voltage | 18 V |
Battery information | |
Battery | Li-Io 14/18/36 V |
Type of battery | n/a |
Noise & vibrations | |
Sound pressure | <70 dB(A) |
Sound standard | ISO15744 |
Vibration standard | ISO28927-2 |
Vibration value | <2.5 m/s² |
Speed | |
Max speed 14V | 500 r/min |
Max speed 18V | 700 r/min |
Max speed 36V | 897 r/min |
Speed range max | 897 r/min |
Speed range min | 50 r/min |
