Model |
Actuation |
Torque Range (Nm) |
Torque Range (in-lb) |
Free Speed (rpm) |
Weight (kg) |
Weight (lb) |
Length (mm) |
Length (in) |
Angle Head Side to Center (mm) |
Angle Head Side to Center (in) |
Angle Head Height (mm) |
Angle Head Height (in) |
Air Inlet |
cfm |
Spindle Type |
Sound (dBA) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
QA1L02S1LD |
Lever Start |
0.4 - 6.37 |
3.5 - 56.4 |
250 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L02S1XLD |
Lever Start |
1.32 - 11.5 |
11.7 - 101.5 |
250 |
1.04 |
2.3 |
330 |
13 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L02S6XLD |
Lever Start |
1.32 - 11.5 |
11.7 - 101.5 |
250 |
1.04 |
2.3 |
330 |
13 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
3/8 in. Square |
75 |
|
QA1L05S1LD |
Lever Start |
0.4 - 6.37 |
3.5 - 56.4 |
500 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L05S1XLD |
Lever Start |
1.32 - 9.98 |
11.7 - 88.3 |
500 |
1.04 |
2.3 |
330 |
13 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L05S4LD |
Lever Start |
0.4 - 6.4 |
3.5 - 56.4 |
500 |
0.9 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Square |
75 |
|
QA1L05S6LD |
Lever Start |
0.4 - 6.37 |
3.5 - 56.4 |
500 |
0.9 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
3/8 in, Square |
75 |
|
QA1L05S6XLD |
Lever Start |
1.32 - 9.98 |
11.7 - 88.3 |
500 |
1.04 |
2.3 |
330 |
13 |
13.2 |
0.52 |
22 |
1.3 |
1/4 in. NPT |
16 |
3/8 in. Square |
75 |
|
QA1L08S1LD |
Lever Start |
0.4 - 5.33 |
3.5 - 47.2 |
850 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L08S4LD |
Lever Start |
0.4 - 5.33 |
3.5 - 47.2 |
850 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Square |
75 |
|
QA1L08S6LD |
Lever Start |
0.4 - 5.33 |
3.5 - 47.2 |
850 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
3/8 in. Square |
75 |
|
QA1L12S1LD |
Lever Start |
0.4 - 3.7 |
3.5 - 32.2 |
1270 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Hex Quick Change |
75 |
|
QA1L12S4LD |
Lever Start |
0.4 - 3.7 |
3.5 - 32.2 |
1270 |
1 |
2.1 |
302.3 |
11.9 |
13.2 |
0.52 |
33 |
1.3 |
1/4 in. NPT |
16 |
1/4 in. Square |
75 |
|
QA1L12S4SD |
Lever Start |
0.4 - 3.7 |
3.5 - 32.2 |
1270 |
0.9 |
1.9 |
300 |
11.8 |
9.5 |
0.38 |
28 |
1.1 |
1/4 in. NPT |
16 |
1/4 in. Square |
75 |
