Model |
Actuation |
Torque Range (Nm) |
Torque Range (ft-lb) |
Free Speed (rpm) |
Weight (kg) |
Weight (lb) |
Length (mm) |
Length (in) |
Angle Head Side to Center (mm) |
Angle Head Side to Center (in) |
Angle Head Height (mm) |
Angle Head Height (in) |
Air Inlet |
cfm |
Spindle Type |
Sound (dBA) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
QA4AALD011NP25S06 |
Lever Start |
11 - 13 |
8 - 9.6 |
1025 |
1.12 |
2.47 |
282 |
11.1 |
13 |
0.5 |
33 |
1.28 |
1/4 in NPT |
27 |
3/8 in. Square |
79.3 |
|
QA4AALD015NP25S06 |
Lever Start |
15 - 16 |
11 - 11.8 |
800 |
1.12 |
2.47 |
282 |
11.1 |
13 |
0.5 |
33 |
1.28 |
1/4 in NPT |
27 |
3/8 in. Square |
79.3 |
|
QA4AALD020NP25S06 |
Lever Start |
20 - 21 |
15 - 15.5 |
625 |
1.12 |
2.47 |
282 |
11.1 |
13 |
0.5 |
33 |
1.28 |
1/4 in NPT |
27 |
3/8 in. Square |
79.3 |
|
QA4AALD030NP28S06 |
Lever Start |
30 - 31 |
22 - 22.9 |
425 |
1.2 |
2.63 |
282 |
11.1 |
14 |
0.55 |
35 |
1.39 |
1/4 in NPT |
27 |
3/8 in. Square |
79.3 |
|
QA4AALD040NP35S06 |
Lever Start |
40 - 41 |
30 - 30.2 |
325 |
1.48 |
3.25 |
335 |
13.2 |
18 |
0.69 |
44 |
1.71 |
1/4 in NPT |
27 |
3/8 in. Square |
79.3 |
|
QA4AALD055NP35S08 |
Lever Start |
55 - 58 |
40 - 42.8 |
200 |
1.76 |
3.88 |
358 |
14.1 |
18 |
0.69 |
44 |
1.71 |
1/4 in NPT |
27 |
1/2 in. Square |
79.3 |
